Brand: EDIBON | Category: Scientific & Laboratory Equipment
Single stage impulse steam turbine with injector, brake and water cooled condenser. A belt brake with load cell measures torque, and closing a solenoid valve at the condenser outlet lets a known volume of condensate be timed to give the steam flow.
| Parameter | Value |
|---|---|
| Specification | Single stage impulse steam turbine |
| Specification | Injector directs the steam onto the blades at an angle of incidence of 20 degrees |
| Specification | Two computer controlled solenoid valves mounted in series on the steam inlet |
| Specification | Water cooled coil condenser with solenoid valve and level sensor for steam flow determination |
| Specification | Brake with belt tensioned by a manual screw, torque measured by a load cell |
| Specification | Pressure switch, safety valve for the condenser and PMMA protection screens |
Contact Vvon Technologies Limited about EDIBON equipment requirements in Bangladesh.
Phone: +880 1711-738207 | Email: info@vvon.com.bd
