BIOBASE Walk-in Fume Hood FH(W) Series
Brand: BIOBASE | Category: Scientific & Laboratory Equipment
BIOBASE Walk-in Fume Hood FH(W) Series is listed in VVON's fume hoods & laboratory ventilation range for Bangladesh. Published models: FH1200(W), FH1500(W), FH1800(W). Check chemical compatibility, extraction method, working space and ducting needs. For a quotation, send the chemicals, process, hood width, extraction route and room utilities. Confirm the exact model, included accessories, consumables, delivery and service scope in the offer. Manufacturer specifications below describe the published configuration; options and local availability require confirmation.
Model specifications
Compare each model column separately. Confirm options and included accessories in your quotation.
| Model | FH1200(W) | FH1500(W) | FH1800(W) |
|---|---|---|---|
| External Size(W*D*H) | 1200*800*2250mm | 1500*800*2250mm | 1800*800*2250mm |
| Internal Size(W*D*H) | 980*550*1670mm | 1280*550*1670mm | 1580*550*1670mm |
| Max Opening | 1300mm | 1300mm | 1300mm |
| Exhaust Airflow Volume | 1150m³/h | 1500m³/h | 1850m³/h |
| Inflow Air Velocity | 0.3~0.8m/s | 0.3~0.8m/s | 0.3~0.8m/s |
| Noise | ≤62dB | ≤62dB | ≤62dB |
| Vibration | Amplitude≤5μm | Amplitude≤5μm | Amplitude≤5μm |
| Illumination | ≥800Lux | ≥800Lux | ≥800Lux |
| Fluorescent Lamp | 12W*2 | 16W*2 | 16W*2 |
| Power Supply | AC220V±10%, 50/60Hz; 110V±10%, 60Hz | AC220V±10%, 50/60Hz; 110V±10%, 60Hz | AC220V±10%, 50/60Hz; 110V±10%, 60Hz |
| Consumption | 400W | 500W | 800W |
| Front Window | Manual, 5mm toughened glass, height adjustable | Manual, 5mm toughened glass, height adjustable | Manual, 5mm toughened glass, height adjustable |
| Material / Exterior | 1.0mm cold-rolled steel with anti-bacteria powder coating. | 1.0mm cold-rolled steel with anti-bacteria powder coating. | 1.0mm cold-rolled steel with anti-bacteria powder coating. |
| Material / Interior | Compact laminate board with good acid and alkali resistance function | Compact laminate board with good acid and alkali resistance function | Compact laminate board with good acid and alkali resistance function |
| Standard Accessory | External blower, LED lamp, Water tap, Gas tap, PP water sink, Water valve, Gas valve, Waterproof sockets*4, 5 meters duct | External blower, LED lamp, Water tap, Gas tap, PP water sink, Water valve, Gas valve, Waterproof sockets*4, 5 meters duct | External blower, LED lamp, Water tap, Gas tap, PP water sink, Water valve, Gas valve, Waterproof sockets*4, 5 meters duct |
| Sockets | Total load of 4 waterproof sockets: ≤500W | Total load of 4 waterproof sockets: ≤500W | Total load of 4 waterproof sockets: ≤500W |
| Package Size(W*D*H) / Main body | 1400*1050*2450mm | 1710*1050*2450mm | 2010*1050*2450mm |
| Package Size(W*D*H) / Exhaust Blower | 970*810*720mm | 1040*890*710mm | 1040*890*710mm |
| Gross Weight | 260kg; 40kg | 290kg; 50kg | 340kg; 50kg |
Manufacturer catalogue checked 2026-09-28.
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Intended application, process or teaching activity
- Required capability and equipment it must work with
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about BIOBASE equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
