BIOBASE Transmission spectrophotometer DS-810
Brand: BIOBASE | Category: Scientific & Laboratory Equipment
BIOBASE Transmission spectrophotometer DS-810 is listed in VVON's spectrometers & optical analysis range for Bangladesh. Published details include Wavelength Range: 400~700nm. Compare measurement range, optical configuration, sample format and software. For a quotation, send the analytical method, measurement range, sample format and software requirements. Confirm the exact model, included accessories, consumables, delivery and service scope in the offer. Manufacturer specifications below describe the published configuration; options and local availability require confirmation.
Model specifications
Compare each model column separately. Confirm options and included accessories in your quotation.
| Measurement Condition | d/0(Scattered light source, 0-degree observation Angle）(CIE No.15、ISO 7724/1、ASTM E1164、DIN 5033 Teil7、JIS Z8722 Condition c) |
|---|---|
| Integrating Sphere | Φ40mm, Avian-D Full diffuse reflection surface coating |
| Lighting Source | CLEDs(Full-band balanced Led light source） |
| Inductor | Dual-optical path sensing array sensor |
| Wavelength Range | 400~700nm |
| Wavelength Coverage | 10nm |
| Half-band Width | 5nm |
| Measuring Range | 0~200% |
| Resolution Ratio | 0.0001 |
| Observer's Perspective | 2°/10° |
| Observe the Light Source | A, C, D50, D55, D65, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12, CMF, U30, DLF, NBF, TL83, TL84 |
| Display | Transmission graph/data, sample chromaticity value, color difference value/graph, pass/fail result, color bias, color simulation, historical data color simulation, manual input of standard sample, test report |
| Measurement Interval | 1s |
| Measure time | 1s |
| Measure Aperture | Φ10mm |
| Color Space | CIE Lab, LCh, CIE Luv, XYZ, Yxy, transmissivity, Hunter Lab Munsel, MI, CMYK |
| Color Difference Formula | ΔE*ab, ΔE*CH, ΔE*uv, ΔE*cmc(2:1), ΔE*cmc(1:1), ΔE*94, ΔE*00 |
| Other Indicators | WI(ASTM E313-00, ASTM E313-73, CIE/ISO, Hunter, Taube Berger Stensby),; YI(ASTM D1925, ASTM E313-00, ASTM E313-73), Tint(ASTM E313-00), Isomerism index Milm, color fastness, Color fastness, APHA, Pt-Co(platinum-to-cobalt index), Gardner(Gardner Index), Saybolt(Sebert Index), Astm Color, Saybolt, ASTM Color |
| Repeatability | Spectral transmittance: Standard deviation within 0.08%, chromaticity value: ΔE*ab 0.015(After correction, measure the standard deviation of air 30 times at intervals of 5 seconds), maximum value |
| Inter-instrument Agreement | ΔE*ab0.2 |
| Data Interface | USB |
| Data Storage | Massive Storage(PC) |
| Size | 475*340*150mm(L*W*H) |
| Weight | 7kg |
| Operating Temperatur | The temperature range is 0 to 45℃, with a relative humidity of 80% or lower(at 35°C), and no water vapor condensation |
| Storage Temperature | From -25°C to 55°C, with a relative humidity of 80% or lower(at 35°C), and no condensation of water vapor |
| Standard Equipment | Power cord, color management software, driver software, data cable, black correction board, 40*10mm cuvette |
| Optional Accessories | 40*33mm cuvette(for measuring ASTM color), 40*100mm cuvette(for measuring Saybolt) |
Manufacturer catalogue checked 2026-09-28.
