Brand: Infitek | Category: Scientific & Laboratory Equipment
Infitek Nitrogen Evaporator/Sample Concentrator, NEC60-R12E is listed in VVON's evaporators concentrators & freeze dryers range for Bangladesh. Published models: NEC60-R12E. Published details include Sample Capacity: 12 position; Temperature Range: RT.~60°C. Match sample volume, solvent, temperature and vacuum requirements. For a quotation, send the sample or solvent, batch size, temperature limits and vacuum accessories. Confirm the exact model, included accessories, consumables, delivery and service scope in the offer. Manufacturer specifications below describe the published configuration; options and local availability require confirmation.
Compare each model column separately. Confirm options and included accessories in your quotation.
| Automated Evaporation Completion With end-point sensor technology, the system can automatically detect the endpoint, which can efficiently concentrate up to your predefined volume to 1.0mL. | End-point Sensor |
|---|---|
| Flexibility The nozzles can be adjustable for left and right angles blowing, which is compatible with a variety of sample tubes. It is commonly used for 60mL and 250mL tubes. The system can automatically supply and drain water, quickly exchange the sample in the water bath. During the evaporation process, the angle of the nitrogen blowing needle can be adjusted, and the horizontal position of the nitrogen blowing needle can be adjusted within a range of ≥ 30mm. | |
| Humanized Design Three-sided transparent glass windows with internal light greatly improves the visibility of the process of nitrogen blowing and concentration. The water bath adopts double-layer glass design to protect users from high temperature. The water tank is equipped with a liquid level sensor, water inlet and water outlet. Water filling and drainage can be controlled by software, and the liquid level can be detected by sensors. | |
| Easy-Use Software Interface With one touch screen airflow rate and temperature operation, with individual tube control. Able to edit and save methods in the software, define and set parameters including temperature, flow rate, nitrogen channels. | Easy-Use Software Interface With one touch screen airflow rate and temperature operation, with individual tube control. Able to edit and save methods in the software, define and set parameters including temperature, flow rate, nitrogen channels. |
| Wide Ranges of Application Concentration of liquid samples in food, water, environment, agricultural pharmaceutical industry, and life science research. | Wide Ranges of Application Concentration of liquid samples in food, water, environment, agricultural pharmaceutical industry, and life science research. |
| Model | NEC60-R12E |
|---|---|
| Concentration | Water bath heating and nitrogen blowing |
| Sample Capacity | 12 position |
| Temperature Range | RT.~60°C |
| Sample Vials | 60mL or 250mL |
| Endpoint Detection | 1.0mL |
| Range of Gas Flow Rate | 0~5.0mL/min, precise to 0.1mL/min |
| Software Interface | 10-inch built-in screen |
| Fume Hood/Ventilation | Required |
| Storage Environment | Temperature: 0~40°C; Humidity: 20%~85% |
| Operating Environment | Temperature: 10~40°C; Humidity: 20%~80% |
| Electricity | 200~240V, 50/60Hz |
| Power Rate | 1500W |
| External Dimension | 580*460*560mm |
| Net Weight | 41kg |
Manufacturer catalogue checked 2026-09-28.
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about Infitek equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
