Infitek Fume Hood, FMH-DF Series
Brand: Infitek | Category: Scientific & Laboratory Equipment
Infitek Fume Hood, FMH-DF Series is listed in VVON's fume hoods & laboratory ventilation range for Bangladesh. Published models: FMH-D3F, FMH-D4F, FMH-D5F, FMH-D6F. Check chemical compatibility, extraction method, working space and ducting needs. For a quotation, send the chemicals, process, hood width, extraction route and room utilities. Confirm the exact model, included accessories, consumables, delivery and service scope in the offer. Manufacturer specifications below describe the published configuration; options and local availability require confirmation.
Model specifications
Compare each model column separately. Confirm options and included accessories in your quotation.
| Model | FMH-D3F | FMH-D4F | FMH-D5F | FMH-D6F |
|---|---|---|---|---|
| External Dimensions (W*D*H)(mm) | 1000*850*2150 | 1220*850*2150 | 1525*850*2150 | 1830*850*2150 |
| Internal Dimensions (W*D*H)(mm) | 880*730*745 | 1100*730*745 | 1405*730*745 | 1710*730*745 |
| Control System | Microprocessor controller with LCD display, graphical and digital display of the operating status of each function. | Microprocessor controller with LCD display, graphical and digital display of the operating status of each function. | Microprocessor controller with LCD display, graphical and digital display of the operating status of each function. | Microprocessor controller with LCD display, graphical and digital display of the operating status of each function. |
| Maximum Opening | 520mm | 520mm | 520mm | 520mm |
| Work Surface Height | 750mm | 750mm | 750mm | 750mm |
| Airflow Velocity | Adjustable, 0.3~0.8 m/s | Adjustable, 0.3~0.8 m/s | Adjustable, 0.3~0.8 m/s | Adjustable, 0.3~0.8 m/s |
| Air Volume(m³/hr)/(cfm) | 657/387 | 868/511 | 1085/639 | 1085/639 |
| Active Carbon Filter / Dimensions(W*D*H)(mm) | 750*495*30 | 1055*495*30 | 1360*495*30 | 1665*495*30 |
| Active Carbon Filter / Quantity | 1pc | 1pc | 1pc | 1pc |
| Sound Emission | ≤68dB(A) | ≤68dB(A) | ≤68dB(A) | ≤68dB(A) |
| Lighting Lamp | 20W*1 | 30W*1 | 30W*1 | 30W*1 |
| Lighting Lamp | LED type | LED type | LED type | LED type |
| UV Lamp | 20W*1 | 30W*1 | 30W*1 | 30W*1 |
| UV Lamp | With timing function, Interlock with front sliding sash. Emission of 253.7 nanometers for best sterilization effect. | With timing function, Interlock with front sliding sash. Emission of 253.7 nanometers for best sterilization effect. | With timing function, Interlock with front sliding sash. Emission of 253.7 nanometers for best sterilization effect. | With timing function, Interlock with front sliding sash. Emission of 253.7 nanometers for best sterilization effect. |
| Power Consumption | 400W | 500W | 500W | 500W |
| Power Consumption | The power consumption does not include external device connected via power socket | The power consumption does not include external device connected via power socket | The power consumption does not include external device connected via power socket | The power consumption does not include external device connected via power socket |
| Cabinet Construction | Main Body: Electro-galvanized steel with antimicrobial powder coating | Main Body: Electro-galvanized steel with antimicrobial powder coating | Main Body: Electro-galvanized steel with antimicrobial powder coating | Main Body: Electro-galvanized steel with antimicrobial powder coating |
| Cabinet Construction | Work Table: Solid physicochemical board, resistant to strong acid and alkali | Work Table: Solid physicochemical board, resistant to strong acid and alkali | Work Table: Solid physicochemical board, resistant to strong acid and alkali | Work Table: Solid physicochemical board, resistant to strong acid and alkali |
| Cabinet Construction | Manual Sliding Sash: 5 mm UV resistant tempered glass with counter-balance system and ergonomic handle | Manual Sliding Sash: 5 mm UV resistant tempered glass with counter-balance system and ergonomic handle | Manual Sliding Sash: 5 mm UV resistant tempered glass with counter-balance system and ergonomic handle | Manual Sliding Sash: 5 mm UV resistant tempered glass with counter-balance system and ergonomic handle |
| Cabinet Construction | Side Windows: 5 mm UV resistant tempered glass | Side Windows: 5 mm UV resistant tempered glass | Side Windows: 5 mm UV resistant tempered glass | Side Windows: 5 mm UV resistant tempered glass |
| Electricity | AC220V ±10%, 50/60Hz,1P | AC220V ±10%, 50/60Hz,1P | AC220V ±10%, 50/60Hz,1P | AC220V ±10%, 50/60Hz,1P |
| Standard Accessories | Base stand*1; LED lamp*1; UV lamp*1; Waterproof socket*2(only 1 for FMH-D3F); Casters with brakes*4; Activated carbon filter*1; Water tap*1; Gas tap*1; Water sink(220*95*150mm)*1; Exhaust duct-10meters*1; Solid physicochemical countertop*1 | Base stand*1; LED lamp*1; UV lamp*1; Waterproof socket*2(only 1 for FMH-D3F); Casters with brakes*4; Activated carbon filter*1; Water tap*1; Gas tap*1; Water sink(220*95*150mm)*1; Exhaust duct-10meters*1; Solid physicochemical countertop*1 | Base stand*1; LED lamp*1; UV lamp*1; Waterproof socket*2(only 1 for FMH-D3F); Casters with brakes*4; Activated carbon filter*1; Water tap*1; Gas tap*1; Water sink(220*95*150mm)*1; Exhaust duct-10meters*1; Solid physicochemical countertop*1 | Base stand*1; LED lamp*1; UV lamp*1; Waterproof socket*2(only 1 for FMH-D3F); Casters with brakes*4; Activated carbon filter*1; Water tap*1; Gas tap*1; Water sink(220*95*150mm)*1; Exhaust duct-10meters*1; Solid physicochemical countertop*1 |
| Optional Accessories | HEPA filter; Wind speed sensor; 304 stainless steel countertop; Base Cabinet | HEPA filter; Wind speed sensor; 304 stainless steel countertop; Base Cabinet | HEPA filter; Wind speed sensor; 304 stainless steel countertop; Base Cabinet | HEPA filter; Wind speed sensor; 304 stainless steel countertop; Base Cabinet |
| Shipping Weight（kg） | 250 | 280 | 330 | 390 |
| Shipping Dimensions （W*D*H）(mm) | 1170*1130*1660 | 1360*1100*1635 | 1665*1100*1635 | 1970*1100*1635 |
| Shipping Volume (m3) | 2.2 | 2.5 | 3.1 | 3.6 |
Manufacturer catalogue checked 2026-09-28.
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Intended application, process or teaching activity
- Required capability and equipment it must work with
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about Infitek equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
