Brand: BIOBASE | Category: Scientific & Laboratory Equipment
BIOBASE Tissue Grinding Machine is listed in VVON's mills sieves & solid sample preparation range for Bangladesh. Published models: BHY2. Match material properties, feed size, output size and contact materials. For a quotation, send the material, feed size, target particle size and batch volume. Confirm the exact model, included accessories, consumables, delivery and service scope in the offer. Manufacturer specifications below describe the published configuration; options and local availability require confirmation.
Compare each model column separately. Confirm options and included accessories in your quotation.
| Model | BHY2 |
|---|---|
| Display | 7-inch OLED touch screen |
| Oscillation Mode | Up and down vertical oscillation |
| Grinding Speed | 500~2300rpm |
| Grinding Way | Dry grinding/wet grinding/low temperature grinding |
| Grinding Time | Each segment 0~120s, can be set in multiple segments |
| Programming | Multi-stage operation setup is available, automatically records the parameters of the last operation |
| Safety Lock | Mechanical butterfly safety lock + door-controlled electronic operation limit |
| Adaptor | Aluminum alloy material |
| Adaptor | Standard: 24*2ml |
| Adaptor | Optional(Can customize): 96*2ml/48*2ml/32*2ml/16*5ml/8*10ml/2*15ml/2*25ml/2*50ml |
| Adaptor | Not suitable for low temperature grinding：96*2ml/48*2ml |
| Grinding Ball | Standard stainless steel grinding ball: φ3mm*800 and φ5mm*200 |
| Consumption | 180W |
| Power Supply | AC110~220V，50/60Hz |
| External Size(W*D*H) | 265*405*520mm |
| Package Size(W*D*H) | 375*530*670mm |
| Net Weight | 29kg |
| Gross Weight | 41kg |
Manufacturer catalogue checked 2026-09-28.
