BIOBASE Precision Differential Pressure Gauge
Brand: BIOBASE | Category: Scientific & Laboratory Equipment
BIOBASE Precision Differential Pressure Gauge is listed in VVON's air quality & cleanroom testing range for Bangladesh. Published models: DPG-100, DPG-200, DPG-500, DPG-101, DPG-201, DPG-310. Compare the remaining models in the specification tables. Match measured parameters, sampling flow, range and calibration requirements. For a quotation, send the application, measured parameter, sampling method and required range. Confirm the exact model, included accessories, consumables, delivery and service scope in the offer. Manufacturer specifications below describe the published configuration; options and local availability require confirmation.
Model specifications
Compare each model column separately. Confirm options and included accessories in your quotation.
| Model | DPG-100 | DPG-200 | DPG-500 | DPG-101 | DPG-201 | DPG-310 | DPG-501 | DPG-111 |
|---|---|---|---|---|---|---|---|---|
| Differential Pressure / Range | 0~±100Pa | 0~±200Pa | 0~±500Pa | 0~±1KPa | 0~±2KPa | 0~±3.5KPa | 0~±5KPa | 0~±9KPa |
| Differential Pressure / Error | ±1%FS | ±1%FS | ±0.5%value/±2Pa(select larger one) | ±0.5%value/±2Pa(select larger one) | ±0.5%value/±2Pa(select larger one) | ±0.5%value/±5Pa(select larger one) | ±0.5%value/±5Pa(select larger one) | ±0.5%value/±10Pa(select larger one) |
| Differential Pressure / Resolution | 0.1Pa | 0.1Pa | 0.1Pa | 0.1Pa | 0.1Pa | 0.1Pa | 0.1Pa | 0.1Pa |
| Wind Speed(optional) / Range | 1~12m/s | 1~18m/s | 1~26m/s | 1~40m/s | 1~55m/s | 1~70m/s | 1~90m/s | 1~120m/s |
| Wind Speed(optional) / Error | 1~5m/s：±0.7 m/s 5~max range value：±2%value or ±0.7 m/s, select larger one (DPG-100, DPG-200, DPG-500) 5~max range value：±3%FS(DPG-101~DPG-111) | 1~5m/s：±0.7 m/s 5~max range value：±2%value or ±0.7 m/s, select larger one (DPG-100, DPG-200, DPG-500) 5~max range value：±3%FS(DPG-101~DPG-111) | 1~5m/s：±0.7 m/s 5~max range value：±2%value or ±0.7 m/s, select larger one (DPG-100, DPG-200, DPG-500) 5~max range value：±3%FS(DPG-101~DPG-111) | 1~5m/s：±0.7 m/s 5~max range value：±2%value or ±0.7 m/s, select larger one (DPG-100, DPG-200, DPG-500) 5~max range value：±3%FS(DPG-101~DPG-111) | 1~5m/s：±0.7 m/s 5~max range value：±2%value or ±0.7 m/s, select larger one (DPG-100, DPG-200, DPG-500) 5~max range value：±3%FS(DPG-101~DPG-111) | 1~5m/s：±0.7 m/s 5~max range value：±2%value or ±0.7 m/s, select larger one (DPG-100, DPG-200, DPG-500) 5~max range value：±3%FS(DPG-101~DPG-111) | 1~5m/s：±0.7 m/s 5~max range value：±2%value or ±0.7 m/s, select larger one (DPG-100, DPG-200, DPG-500) 5~max range value：±3%FS(DPG-101~DPG-111) | 1~5m/s：±0.7 m/s 5~max range value：±2%value or ±0.7 m/s, select larger one (DPG-100, DPG-200, DPG-500) 5~max range value：±3%FS(DPG-101~DPG-111) |
| Wind Speed(optional) / Resolution | 0.1m/s(1m/s when exceeds 100) | 0.1m/s(1m/s when exceeds 100) | 0.1m/s(1m/s when exceeds 100) | 0.1m/s(1m/s when exceeds 100) | 0.1m/s(1m/s when exceeds 100) | 0.1m/s(1m/s when exceeds 100) | 0.1m/s(1m/s when exceeds 100) | 0.1m/s(1m/s when exceeds 100) |
| Temp / Range | -40~85℃ | -40~85℃ | -40~85℃ | -40~85℃ | -40~85℃ | -40~85℃ | -40~85℃ | -40~85℃ |
| Temp / Error | ≤±0.3℃ | ≤±0.3℃ | ≤±0.3℃ | ≤±0.3℃ | ≤±0.3℃ | ≤±0.3℃ | ≤±0.3℃ | ≤±0.3℃ |
| Temp / Resolution | 0.1℃ | 0.1℃ | 0.1℃ | 0.1℃ | 0.1℃ | 0.1℃ | 0.1℃ | 0.1℃ |
| Humidity / Range | 0~99%RH | 0~99%RH | 0~99%RH | 0~99%RH | 0~99%RH | 0~99%RH | 0~99%RH | 0~99%RH |
| Humidity / Error | ≤±2%RH | ≤±2%RH | ≤±2%RH | ≤±2%RH | ≤±2%RH | ≤±2%RH | ≤±2%RH | ≤±2%RH |
| Humidity / Resolution | 0.1%RH | 0.1%RH | 0.1%RH | 0.1%RH | 0.1%RH | 0.1%RH | 0.1%RH | 0.1%RH |
| Power Supply | AAA battery*4 | AAA battery*4 | AAA battery*4 | AAA battery*4 | AAA battery*4 | AAA battery*4 | AAA battery*4 | AAA battery*4 |
| Standard accessory | Φ4mm*1m silicone hose*2, portable box, usb interface | Φ4mm*1m silicone hose*2, portable box, usb interface | Φ4mm*1m silicone hose*2, portable box, usb interface | Φ4mm*1m silicone hose*2, portable box, usb interface | Φ4mm*1m silicone hose*2, portable box, usb interface | Φ4mm*1m silicone hose*2, portable box, usb interface | Φ4mm*1m silicone hose*2, portable box, usb interface | Φ4mm*1m silicone hose*2, portable box, usb interface |
| Optional accessory | Pitot tube | Pitot tube | Pitot tube | Pitot tube | Pitot tube | Pitot tube | Pitot tube | Pitot tube |
| External Size | 217*97*46mm | 217*97*46mm | 217*97*46mm | 217*97*46mm | 217*97*46mm | 217*97*46mm | 217*97*46mm | 217*97*46mm |
| Package Size | 360*290*105mm | 360*290*105mm | 360*290*105mm | 360*290*105mm | 360*290*105mm | 360*290*105mm | 360*290*105mm | 360*290*105mm |
| Net/Gross Weight | 0.6kg/2kg | 0.6kg/2kg | 0.6kg/2kg | 0.6kg/2kg | 0.6kg/2kg | 0.6kg/2kg | 0.6kg/2kg | 0.6kg/2kg |
Manufacturer catalogue checked 2026-09-28.
