BIOBASE Ducted Fume Hood FH(X) series
Brand: BIOBASE | Category: Scientific & Laboratory Equipment
BIOBASE Ducted Fume Hood FH(X) series is listed in VVON's fume hoods & laboratory ventilation range for Bangladesh. Published models: FH1000(X), FH1200(X), FH1500(X), FH1800(X). Check chemical compatibility, extraction method, working space and ducting needs. For a quotation, send the chemicals, process, hood width, extraction route and room utilities. Confirm the exact model, included accessories, consumables, delivery and service scope in the offer. Manufacturer specifications below describe the published configuration; options and local availability require confirmation.
Model specifications
Compare each model column separately. Confirm options and included accessories in your quotation.
| Model | FH1000(X) | FH1200(X) | FH1500(X) | FH1800(X) |
|---|---|---|---|---|
| External Size(W*D*H) | 1000*840*2150mm | 1200*840*2150mm | 1500*840*2150mm | 1800*840*2150mm |
| Internal Size(W*D*H) | 880*730*745mm | 1080*730*745mm | 1380*730*745mm | 1680*730*745mm |
| Max Opening | 520mm | 520mm | 520mm | 520mm |
| Work Surface Height | 750mm | 750mm | 750mm | 750mm |
| Blower | Built-in centrifugal blowers, Speed adjustable with 9 levels | Built-in centrifugal blowers, Speed adjustable with 9 levels | Built-in centrifugal blowers, Speed adjustable with 9 levels | Built-in centrifugal blowers, Speed adjustable with 9 levels |
| Air Velocity | 0.3~0.8m/s | 0.3~0.8m/s | 0.3~0.8m/s | 0.3~0.8m/s |
| System Exhaust Volume | 630m³/h | 780m³/h | 990m³/h | 1210m³/h |
| Noise | ≤68dB | ≤68dB | ≤68dB | ≤68dB |
| LED Lamp | 8W*1 for 110V 20W*1 for 220V | 12W*1 for 110V 20W*1 for 220V | 16W*1 for 110V 40W*1 for 220V | 16W*1 for 110V 40W*1 for 220V |
| UV Lamp ; | 20W | 20W | 30W | 30W |
| UV Lamp ; | Emission of 253.7 nanometers for most efficient decontamination | Emission of 253.7 nanometers for most efficient decontamination | Emission of 253.7 nanometers for most efficient decontamination | Emission of 253.7 nanometers for most efficient decontamination |
| Front Window | Motorized; 5 mm toughened glass, anti-UV | Motorized; 5 mm toughened glass, anti-UV | Motorized; 5 mm toughened glass, anti-UV | Motorized; 5 mm toughened glass, anti-UV |
| Material | Exterior body: Cold-rolled steel with anti-bacteria powder coating. Work table: Chemical resistant phenolic resin | Exterior body: Cold-rolled steel with anti-bacteria powder coating. Work table: Chemical resistant phenolic resin | Exterior body: Cold-rolled steel with anti-bacteria powder coating. Work table: Chemical resistant phenolic resin | Exterior body: Cold-rolled steel with anti-bacteria powder coating. Work table: Chemical resistant phenolic resin |
| Waterproof Socket | 1pc | 2pcs | 2pcs | 2pcs |
| Power Supply | AC220V±10%, 50/60Hz; 110V±10%, 60Hz | AC220V±10%, 50/60Hz; 110V±10%, 60Hz | AC220V±10%, 50/60Hz; 110V±10%, 60Hz | AC220V±10%, 50/60Hz; 110V±10%, 60Hz |
| Consumption | 400W | 400W | 500W | 500W |
| Standard Accessory | Water tap, Gas tap, Water sink, Base stand, UV lamp*2, LED lamp, Socket, 5 meters exhaust duct, Active carbon filter, Foot switch | Water tap, Gas tap, Water sink, Base stand, UV lamp*2, LED lamp, Socket, 5 meters exhaust duct, Active carbon filter, Foot switch | Water tap, Gas tap, Water sink, Base stand, UV lamp*2, LED lamp, Socket, 5 meters exhaust duct, Active carbon filter, Foot switch | Water tap, Gas tap, Water sink, Base stand, UV lamp*2, LED lamp, Socket, 5 meters exhaust duct, Active carbon filter, Foot switch |
| Optional Accessory | HEPA filter | HEPA filter | HEPA filter | HEPA filter |
| Gross Weight | 230kg | 253kg | 290kg | 340kg |
| Package Size(W*D*H) | 1150*1120*1680mm | 1350*1120*1680mm | 1650*1120*1680mm | 1950*1120*1680mm |
Manufacturer catalogue checked 2026-09-28.
