Brand: EDIBON | Category: Scientific & Laboratory Equipment
Deals with components whose operation depends on light, both emitters inside and outside the visible spectrum and light sensitive devices. Students measure their characteristics and build typical optoelectronic circuits, with fault simulation available for diagnosis.
| Parameter | Value |
|---|---|
| Dimensions | 300 x 210 x 45 mm |
| Weight | 300 g approx |
