Infitek Peristaltic Pump, PP-Z400/PH-Z1880
Brand: Infitek | Category: Scientific & Laboratory Equipment
Infitek Peristaltic Pump, PP-Z400/PH-Z1880 is listed in VVON's ph conductivity & water analysis range for Bangladesh. Match measured parameters, range, probe compatibility and sample conditions. For a quotation, send the water or sample type, parameters, range, probe and calibration requirements. Confirm the exact model, included accessories, consumables, delivery and service scope in the offer. Manufacturer specifications below describe the published configuration; options and local availability require confirmation.
Model specifications
Compare each model column separately. Confirm options and included accessories in your quotation.
| Drive Model: PP-Z400 | Drive Model: PP-Z400 | Drive Model: PP-Z400 | Drive Model: PP-Z400 | Pump head model: PH-Z1880 | Pump head model: PH-Z1880 | Pump head model: PH-Z1880 | Pump head model: PH-Z1880 |
|---|---|---|---|---|---|---|---|
| RPM | 0.1-400rpm | Dispensing time | 0.1-999.9S | Using tubing | 15#、24#、35#、36# | 15#、24#、35#、36# | 15#、24#、35#、36# |
| Speed resolution | 0.1rpm(≤100rpm); 1rpm(＞100rpm) | Dispensing volume | 400μL-9999L | Flow range | 0.169-1880mL/min | 0.169-1880mL/min | 0.169-1880mL/min |
| Filling volume resolution | 0.001-0.01mL; (Different according to the tubing) | Times | 0-9999; (0 Infinite loop) | Tubing wall | 2.4mm | Roller seal | Yes |
| Repeat error | ±0.5% | Intervals | 0.1-999.9s | Pressure adjust | No | Factory pressure | 0.15Mpa |
| Retention error | 100rpm，1% within 68 hours; (Filling special tube) | Suction angle | 0-720° | Shell material | PPS | PPS | PPS |
| Display | LCD screen (3.5 inch) | Protection level | IP31 | Roller material | SS | SS | SS |
| Operation | Membrane keypad +Digital control knob | Power | ≤45W | Roller No. | 4 | 4 | 4 |
| Working environment | Temperature, 0℃ to 40℃; Relative humidity < 80% | Weight | 6.8kg | Product No. | 2022503 | 2022503 | 2022503 |
| External speed control | 0-5V (optional)、0-10V (optional)、4-20mA (standard), 0-10K (standard) | 0-5V (optional)、0-10V (optional)、4-20mA (standard), 0-10K (standard) | 0-5V (optional)、0-10V (optional)、4-20mA (standard), 0-10K (standard) | 0-5V (optional)、0-10V (optional)、4-20mA (standard), 0-10K (standard) | 0-5V (optional)、0-10V (optional)、4-20mA (standard), 0-10K (standard) | 0-5V (optional)、0-10V (optional)、4-20mA (standard), 0-10K (standard) | 0-5V (optional)、0-10V (optional)、4-20mA (standard), 0-10K (standard) |
| Type of external control | Start /stop, Direction change TTL 5V (standard), TTL 12V (optional), TTL 24V (optional) | Start /stop, Direction change TTL 5V (standard), TTL 12V (optional), TTL 24V (optional) | Start /stop, Direction change TTL 5V (standard), TTL 12V (optional), TTL 24V (optional) | Start /stop, Direction change TTL 5V (standard), TTL 12V (optional), TTL 24V (optional) | Start /stop, Direction change TTL 5V (standard), TTL 12V (optional), TTL 24V (optional) | Start /stop, Direction change TTL 5V (standard), TTL 12V (optional), TTL 24V (optional) | Start /stop, Direction change TTL 5V (standard), TTL 12V (optional), TTL 24V (optional) |
| Port output | DC12V Power Output; DC5V TTL Output (optional) | DC12V Power Output; DC5V TTL Output (optional) | DC12V Power Output; DC5V TTL Output (optional) | DC12V Power Output; DC5V TTL Output (optional) | DC12V Power Output; DC5V TTL Output (optional) | DC12V Power Output; DC5V TTL Output (optional) | DC12V Power Output; DC5V TTL Output (optional) |
| Communication Interface | RS232, RS485 (Start/stop, Direction change, speed control) | RS232, RS485 (Start/stop, Direction change, speed control) | RS232, RS485 (Start/stop, Direction change, speed control) | RS232, RS485 (Start/stop, Direction change, speed control) | RS232, RS485 (Start/stop, Direction change, speed control) | RS232, RS485 (Start/stop, Direction change, speed control) | RS232, RS485 (Start/stop, Direction change, speed control) |
| Power supply | AC220V±10%, 50Hz/60Hz(standard); AC110V±10%, 50Hz/60Hz; AC380V±10%, 50Hz/60Hz(optional) | AC220V±10%, 50Hz/60Hz(standard); AC110V±10%, 50Hz/60Hz; AC380V±10%, 50Hz/60Hz(optional) | AC220V±10%, 50Hz/60Hz(standard); AC110V±10%, 50Hz/60Hz; AC380V±10%, 50Hz/60Hz(optional) | AC220V±10%, 50Hz/60Hz(standard); AC110V±10%, 50Hz/60Hz; AC380V±10%, 50Hz/60Hz(optional) | AC220V±10%, 50Hz/60Hz(standard); AC110V±10%, 50Hz/60Hz; AC380V±10%, 50Hz/60Hz(optional) | AC220V±10%, 50Hz/60Hz(standard); AC110V±10%, 50Hz/60Hz; AC380V±10%, 50Hz/60Hz(optional) | AC220V±10%, 50Hz/60Hz(standard); AC110V±10%, 50Hz/60Hz; AC380V±10%, 50Hz/60Hz(optional) |
| Package Dimension (W*D*H)(mm) | 390*340*280 | 390*340*280 | 390*340*280 | 390*340*280 | 390*340*280 | 390*340*280 | 390*340*280 |
| G.W.(kg) | 8 | 8 | 8 | 8 | 8 | 8 | 8 |
Manufacturer catalogue checked 2026-09-28.
