Infitek Autoclave, Class N, Horizontal Type, STH-ND Series
Brand: Infitek | Category: Scientific & Laboratory Equipment
Infitek Autoclave, Class N, Horizontal Type, STH-ND Series is listed in VVON's autoclaves & sterilisation equipment range for Bangladesh. Published models: STH-N150D, STH-N200D, STH-N300D, STH-N400D. Match chamber size, load type, cycle requirements and available utilities. For a quotation, send the load type, chamber capacity, cycle requirements and utilities. Confirm the exact model, included accessories, consumables, delivery and service scope in the offer. Manufacturer specifications below describe the published configuration; options and local availability require confirmation.
Model specifications
Compare each model column separately. Confirm options and included accessories in your quotation.
| Model | STH-N150D | STH-N200D | STH-N300D | STH-N400D |
|---|---|---|---|---|
| Volume（L） | 150 | 200 | 300 | 400 |
| Overall Dimensions | 1260*690*1740 | 1490*690*1740 | 1400*850*1760 | 1680*850*1760 |
| (L*W*H)mm | 1260*690*1740 | 1490*690*1740 | 1400*850*1760 | 1680*850*1760 |
| Chamber Size(Ø*L)mm | φ472*880 | φ472*1150 | φ620*995 | φ620*1320 |
| Steam Consumption (kg) | ≤13 | ≤15 | ≤20 | ≤25 |
| Water Consumption(kg) | ≤30 | ≤35 | ≤40 | ≤45 |
| Power(kW) | ≤18 | ≤23 | ≤23 | ≤23 |
| N.W. / G.W. (kg) | 390/470 | 435/535 | 540/645 | 630/740 |
| Design Pressure | -0.1~0.3MPa |
|---|---|
| Design Temperature | 150℃ |
| Working Pressure | 0.23MPa |
| Working Temperature | 115~138℃ |
| Temperature Equilibrium | <+2.0℃ |
| Vacuum | -0.086MPa |
| Water Pressure | 0.1-0.2MPa |
| Compressed Air Pressure | 0.4~0.7MPa |
| Steam Pressure | 0.3~0.7MPa |
| Power Voltage | Three-phase five-wire AC380V/50Hz |
Manufacturer catalogue checked 2026-09-28.
