BIOBASE IVC Mouse Cage System
Brand: BIOBASE | Category: Medical Equipment
BIOBASE IVC Mouse Cage System is listed in VVON's veterinary laboratory equipment range for Bangladesh. Published models: BK-IVC-SL500-24(4*6)-1, BK-IVC-SL500-30(5*6)-1, BK-IVC-SL500-36(6*6)-1, BK-IVC-SL500-48(4*6)-2, BK-IVC-SL500-60(5*6)-2, BK-IVC-SL500-72(6*6)-2. Compare the remaining models in the specification tables. Check supported species, sample type, test menu and consumable compatibility. For a quotation, send the species, sample type, expected workload and consumables. Confirm the exact model, included accessories, consumables, delivery and service scope in the offer. Manufacturer specifications below describe the published configuration; options and local availability require confirmation.
Model specifications
Compare each model column separately. Confirm options and included accessories in your quotation.
| Ventilation Rate | 10~85 times/h |
|---|---|
| Airflow Velocity | ≤0.1m/s |
| Air Cleanliness | ISO Level 5 |
| Noise | ≤55dB |
| Colony Number | 0 |
| Pressure Difference | ≥10pa |
| Power Supply | 110~220V, 50/60Hz |
| External Size | 470*605*1550mm |
| Package Size | 570*705*1700mm |
| Gross Weight | 105kg |
| Model | Cage Number(pc) | Cage Frame Size(L*W*H)mm | Cage Size(L*W*H)mm | Packing Information | Packing Information | Packing Information | Packing Information |
|---|---|---|---|---|---|---|---|
| Model | Cage Number(pc) | Cage Frame Size(L*W*H)mm | Cage Size(L*W*H)mm | Main Unit Packing Size(L*W*H)mm | Main Unit Gross Weight(kg) | Cage Frame&Cage Packing Size(L*W*H)mm | Cage Frame&Cage Gross Weight(kg) |
| BK-IVC-SL500-24(4*6)-1 | 24 | 1186*540*1945 | 500*274*226 | 754*620*2060 | 115 | 1706*670*2162 | 107 |
| BK-IVC-SL500-30(5*6)-1 | 30 | 1475*540*1945 | 500*274*226 | 754*620*2060 | 115 | 1995*670*2162 | 126 |
| BK-IVC-SL500-36(6*6)-1 | 36 | 1764*540*1945 | 500*274*226 | 754*620*2060 | 115 | 2284*670*2162 | 145 |
| BK-IVC-SL500-48(4*6)-2 | 48 | 1186*540*1945 | 500*274*226 | 754*620*2060 | 115 | 1706*1210*2162 | 205 |
| BK-IVC-SL500-60(5*6)-2 | 60 | 1475*540*1945 | 500*274*226 | 754*620*2060 | 115 | 1995*1210*2162 | 241 |
| BK-IVC-SL500-72(6*6)-2 | 72 | 1764*540*1945 | 500*274*226 | 754*620*2060 | 115 | 2284*1210*2162 | 278 |
| Model | Cage Number(pc) | Cage Frame Size(L*W*H)mm | Cage Size(L*W*H)mm | Packing Information | Packing Information | Packing Information | Packing Information |
|---|---|---|---|---|---|---|---|
| Model | Cage Number(pc) | Cage Frame Size(L*W*H)mm | Cage Size(L*W*H)mm | Main Unit Packing Size(L*W*H)mm | Main Unit Gross Weight(kg) | Cage Frame&Cage Packing Size(L*W*H)mm | Cage Frame&Cage Gross Weight(kg) |
| BK-IVC-SL385-32(4*8)-1 | 32 | 806*490*1812 | 400*179*166 | 754*620*2060 | 115 | 1326*620*2029 | 105 |
| BK-IVC-SL385-36(4*9)-1 | 36 | 806*490*2005 | 400*179*166 | 754*620*2060 | 115 | 1326*620*2222 | 111 |
| BK-IVC-SL385-40(5*8)-1 | 40 | 1000*490*1812 | 400*179*166 | 754*620*2060 | 115 | 1520*620*2029 | 119 |
| BK-IVC-SL385-45(5*9)-1 | 45 | 1000*490*2005 | 400*179*166 | 754*620*2060 | 115 | 1520*620*2222 | 125 |
| BK-IVC-SL385-48(6*8)-1 | 48 | 1194*490*1812 | 400*179*166 | 754*620*2060 | 115 | 1714*620*2029 | 133 |
| BK-IVC-SL385-54(6*9)-1 | 54 | 1194*490*2005 | 400*179*166 | 754*620*2060 | 115 | 1714*620*2222 | 139 |
| BK-IVC-SL385-56(7*8)-1 | 56 | 1388*490*1812 | 400*179*166 | 754*620*2060 | 115 | 1908*620*2029 | 143 |
| BK-IVC-SL385-63(7*9)-1 | 63 | 1388*490*2005 | 400*179*166 | 754*620*2060 | 115 | 1908*620*2222 | 150 |
| BK-IVC-SL385-64(8*8)-1 | 64 | 1582*490*1812 | 400*179*166 | 754*620*2060 | 115 | 2102*620*2029 | 159 |
| BK-IVC-SL385-72(8*9)-1 | 72 | 1582*490*2005 | 400*179*166 | 754*620*2060 | 115 | 2102*620*2222 | 165 |
| BK-IVC-SL385-72(9*8)-1 | 72 | 1776*490*1812 | 400*179*166 | 754*620*2060 | 115 | 2296*620*2029 | 169 |
| BK-IVC-SL385-81(9*9)-1 | 81 | 1776*490*2005 | 400*179*166 | 754*620*2060 | 115 | 2296*620*2222 | 176 |
| BK-IVC-SL385-96(6*8)-SM-1 | 96 | 1194*890*1812 | 400*179*166 | 754*620*2060 | 115 | 1714*1020*2029 | 169 |
| BK-IVC-SL385-108(6*9)-SM-1 | 108 | 1194*890*2005 | 400*179*166 | 754*620*2060 | 115 | 1714*1020*2222 | 180 |
| BK-IVC-SL385-112(7*8)-SM-1 | 112 | 1388*890*1812 | 400*179*166 | 754*620*2060 | 115 | 1908*1020*2029 | 186 |
| BK-IVC-SL385-126(7*9)-SM-1 | 126 | 1388*890*2005 | 400*179*166 | 754*620*2060 | 115 | 1908*1020*2222 | 198 |
| BK-IVC-SL385-128(8*8)-SM-1 | 128 | 1582*890*1812 | 400*179*166 | 754*620*2060 | 115 | 2102*1020*2029 | 204 |
| BK-IVC-SL385-144(8*9)-SM-1 | 144 | 1582*890*2005 | 400*179*166 | 754*620*2060 | 115 | 2102*1020*2222 | 216 |
| BK-IVC-SL385-144(9*8)-SM-1 | 144 | 1776*890*1812 | 400*179*166 | 754*620*2060 | 115 | 2296*1020*2029 | 231 |
| BK-IVC-SL385-96(6*8)-2 | 96 | 1194*490*1812 | 400*179*166 | 754*620*2060 | 115 | 1714*1110*2029 | 256 |
| BK-IVC-SL385-108(6*9)-2 | 108 | 1194*490*2005 | 400*179*166 | 754*620*2060 | 115 | 1714*1110*2222 | 268 |
| BK-IVC-SL385-112(7*8)-2 | 112 | 1388*490*1812 | 400*179*166 | 754*620*2060 | 115 | 1908*1110*2029 | 275 |
| BK-IVC-SL385-126(7*9)-2 | 126 | 1388*490*2005 | 400*179*166 | 754*620*2060 | 115 | 1908*1110*2222 | 288 |
| BK-IVC-SL385-128(8*8)-2 | 128 | 1582*490*1812 | 400*179*166 | 754*620*2060 | 115 | 2102*1110*2029 | 305 |
| BK-IVC-SL385-144(8*9)-2 | 144 | 1582*490*2005 | 400*179*166 | 754*620*2060 | 115 | 2102*1110*2222 | 318 |
| BK-IVC-SL385-144(9*8)-2 | 144 | 1776*490*1812 | 400*179*166 | 754*620*2060 | 115 | 2296*1110*2029 | 325 |
| BK-IVC-SL385-162(9*9)-2 | 162 | 1776*490*2005 | 400*179*166 | 754*620*2060 | 115 | 2296*1110*2222 | 338 |
| BK-IVC-SL385-192(6*8)-SM-2 | 192 | 1194*890*1812 | 400*179*166 | 754*620*2060 | 115 | 1714*1910*2029 | 327 |
| BK-IVC-SL385-216(6*9)-SM-2 | 216 | 1194*890*2005 | 400*179*166 | 754*620*2060 | 115 | 1714*1910*2222 | 351 |
| BK-IVC-SL385-224(7*8)-SM-2 | 224 | 1388*890*1812 | 400*179*166 | 754*620*2060 | 115 | 1908*1910*2029 | 361 |
| BK-IVC-SL385-252(7*9)-SM-2 | 252 | 1388*890*2005 | 400*179*166 | 754*620*2060 | 115 | 1908*1910*2222 | 384 |
| BK-IVC-SL385-256(8*8)-SM-2 | 256 | 1582*890*1812 | 400*179*166 | 754*620*2060 | 115 | 2102*1910*2029 | 396 |
| BK-IVC-SL385-288(8*9)-SM-2 | 288 | 1582*890*2005 | 400*179*166 | 754*620*2060 | 115 | 2102*1910*2222 | 420 |
| BK-IVC-SL385-288(9*8)-SM-2 | 288 | 1776*890*1812 | 400*179*166 | 754*620*2060 | 115 | 2296*1910*2029 | 450 |
| Model | Cage Number(pc) | Cage Frame Size(L*W*H)mm | Cage Size(L*W*H)mm | Packing Information | Packing Information | Packing Information | Packing Information |
|---|---|---|---|---|---|---|---|
| Model | Cage Number(pc) | Cage Frame Size(L*W*H)mm | Cage Size(L*W*H)mm | Main Unit Packing Size(L*W*H)mm | Main Unit Gross Weight(kg) | Cage Frame&Cage Packing Size(L*W*H)mm | Cage Frame&Cage Gross Weight(kg) |
| BK-IVC-SL520-16(4*4)-1 | 16 | 1638*580*1476 | 520*389*270 | 754*620*2060 | 115 | 2158*710*1693 | 121 |
| BK-IVC-SL520-20(4*5)-1 | 20 | 1638*580*1781 | 520*389*270 | 754*620*2060 | 115 | 2158*710*1998 | 142 |
| BK-IVC-SL520-32(4*4)-2 | 32 | 1638*580*1476 | 520*389*270 | 754*620*2060 | 115 | 2158*1290*1693 | 234 |
| BK-IVC-SL520-40(4*5)-2 | 40 | 1638*580*1781 | 520*389*270 | 754*620*2060 | 115 | 2158*1290*1998 | 274 |
| Model | Cage Number(pc) | Cage Frame Size(L*W*H)mm | Cage Size(L*W*H)mm | Packing Information | Packing Information | Packing Information | Packing Information |
|---|---|---|---|---|---|---|---|
| Model | Cage Number(pc) | Cage Frame Size(L*W*H)mm | Cage Size(L*W*H)mm | Main Unit Packing Size(L*W*H)mm | Main Unit Gross Weight(kg) | Cage Frame&Cage Packing Size(L*W*H)mm | Cage Frame&Cage Gross Weight(kg) |
| BK-IVC-TL520-12(3*4)-1 | 12 | 1236*580*2026 | 520*385*415 | 754*620*2060 | 115 | 1756*710*2243 | 116 |
| BK-IVC-TL520-16(4*4)-1 | 16 | 1638*580*2026 | 520*385*415 | 754*620*2060 | 115 | 2158*710*2243 | 145 |
| BK-IVC-TL520-24(3*4)-2 | 24 | 1236*580*2026 | 520*385*415 | 754*620*2060 | 115 | 1756*1290*2243 | 223 |
| BK-IVC-TL520-32(4*4)-2 | 32 | 1638*580*2026 | 520*385*415 | 754*620*2060 | 115 | 2158*1290*2243 | 279 |
Manufacturer catalogue checked 2026-09-28.
